iFlowScreen

Overview

iFlowScreen a tool that helps you to filter flows from NetFlow, IPFIX and sFlow packets that you are not interested in. iFlowScreen stands as a proxy server between your flow exporters and flow collectors. The core of its operations is to accept UDP flow packet, deconstruct it into flows carried inside, drop flows that are classified as "no interesting", reconstruct packet and send it to flow collectors. By filtering unwanted flows, you will be able to save our money lowering required licenses for flow collector, lowering RAM, CPU and disk necessity. This is depicted in a diagram below:

Products main objective is to save your money by lowering number of flows that your existing flow collectors must process. There are few reasons why you would want to do that:

To save money on licensing by sending less flow to flow collector, thus requiring less licenses for flows per second.
To lower processing requirement of your flow collectors - less RAM and less CPU will be required.
To lower disk space requirements of your flow collectors - by receiving less flows, flow collector will need less disk space to store historical data.

Benefits

Modern and secure

Platform utilizes modern user security approaches provided by Spring boot framework.

Multi-platform

System can be installed on any operating systems that has Docker and JAVA support.

Fast

Newest multi-threading and parallel computing methods applied.

Money-saving

Filter what you don't need, and you will save on licenses, RAM, CPU and HDD.

TECHNICAL SPECIFICATION

“iFlowScreen” is a solution designed to filter unwanted flows from NetFlow, IPFIX and sFlow protocols. NetFlow, IPFIX and sFlow flows are deconstructed, filtered and reconstructed matching the following attributes in flows if they exist:

Source IP address
Destination IP address
Source interface
Destination interface
MPLS label

For every exporting router there can be multiple rules matching any of the five above attributes. One rule intended to match all attributes in it. If rule is not matched, another rule is checked.

Modules

“iFlowScreen” has modular architecture. Table below describes the modules that are possible to order.

Module	Description	Code
Base	No filtering, just forwarding traffic and showing statistic information in passing flows. No FPS licenses are required.	iFLOWSCREEN-BASE-01-W=
NetFlowFilter	Filtering of NetFlow v5 and Netflow v9 flows.	iFLOWSCREEN -NF-01-W=
IPFIXFilter	Filtering of IPFIX flows.	iFLOWSCREEN -iF-01-W=
sFlowFilter	Filtering of sFlow flows.	iFLOWSCREEN -SF-01-W=
FPS	Flows per second license required for filtering traffic. Base license does not require this license.	iFLOWSCREEN -FPS-01-W=
